1.Scope of Application
Rolling shear is a large plate shearing equipment formed in the development of plate shearing equipment. The roll cutting sizing shear is mainly used in the finishing production line of medium and thick plates to cut, segment and size the incoming medium and thick plates, and to produce finished steel plates that meet the specification and length requirements.
2.Specification
Specification and thickness of sheared finished product (mm): 5mm ～ 50mm
Shearing times/min: start and stop shearing 10~13 times/min
3.Product Introduction
At present, the domestic rolling cut sizing shears are mainly motor driven, with two shafts and two eccentricities. The shear blade is driven by the crankshaft and moves in a circle to complete the shearing of incoming materials.
Through the joint design with German SMS Company and British VAI Company, our company has provided multiple sets of rolling cut sizing shears for production of many domestic metallurgical manufacturers. Based on the joint design, the transformation and absorption of international technologies have enabled the independent R&D and design of a full set of equipment, which can meet the production needs of different specifications of plate widths, occupy most of the domestic market for medium and thick plate cutting equipment, and is our company's superior product. The roll cut sizing shear developed and designed by our company has the characteristics of large shear thickness range, smooth cut, no steps, no bending, high output, low energy consumption, long service life, high automation level, etc. At present, our company is an advanced enterprise in China that has mastered all the technologies of design, manufacturing, installation and commissioning of rolling cut sizing shear.
4.Main Experiences in Recent Years
32 sets at home and abroad, such as Ansteel, Baotou Steel, Vietnam and American projects
